Pololu USB/RC/TTL/analog HP Motor Controller (24v23) 23A for brushed DC motors, USB, TTL, RC, analog voltage, bidirectional control

Item number: PO-1383

EAN: 4251326822982

Very compact single DC motor controller USB, RC, analog, TTL 5.5V up to 40V 23A Continuous load without heat sink Parts kit, simple soldering required

Category: Motordriver

68,40 €

including 19% VAT. , plus shipping (Standard)

availability on request (delivery time usually 5-10 working days)

The Polulu USB/RC/TTL/serial/analog HP Motor Controller is a simple high performance motor controller from Polulu. The HP Motor Controller is a versatile motor controller for controlled DC motors.

Please note that this version is the partially assembled kit. The Löten is easy to handle.

A wide range of applications from up to V and the ability to deliver up to several hundred watts in a small form factor make the HP motor controller suitable for various motor controller applications. The motor controller supports the following interfaces: USB, TTL serial, RC Hobby and analog voltage. Due to these supported interfaces and a variety of configurable settings, it is easy for the motor controller to add basic controls to various projects.

Although the HP Motor Controller 23 A has much more features than competing products, a free configuration utility (for Windows 7, Vista, Windows XP and Linux) simplifies the basic settings of the device and allows in-system testing and monitoring of the controller via USB.

    Main features
  • Simple bidirectional control of a Brushed DC Motor
  • Operating voltage range: 5.5 to 40 V
  • Maximum continuous current without heat trap: 23 A
  • Vier communication or control options
    1. USB interface for direct connection with PC
    2. TTL serial interface for direct connection with microcontroller or other embedded controllers
    3. Radio control interface for direct connection with RC receiver or RC servo controller
    4. 0 to 3.3 V analog voltage interface for direct connection to potentiometer and analog joysticks
  • Simple configuration and calibration via USB with free configuration program (compatible with Windows 7, Vista, Windows XP and Linux)

Please note that you will need a USB A to Mini-B cable to connect the motor controller to a PC.

    Other Features:
  • Adjustable maximum acceleration and deceleration to limit electrical and mechanical load on the system
  • Settable initial speed, maximum speed and amount of braking when speed is zero
  • Optional safety control to avoid unexpected power supply
  • Input calibration (learning) and adjustable scaling level for analog and RC signals
  • Undervoltage cut-off with hysteresis for use with batteries which are susceptible to deep discharge (e.g. LiPo cells)
  • Settable temperature threshold and resonance
  • >Adjustable PWM frequency from 1 kHz to 22 kHz
  • Error LED connected to a digital ERR output; if error output from multiple controllers is connected, all connected controllers will fail if one detects an error
  • Functional expandable firmware
    USB and serial features:
  • Controllable from a computer with a native USB, serial commands are sent to the virtual serial (COM) port or via TTL serial through the RX/TX poles of the device
  • Example code in C#, Visual Basic .NET and Visual C++ is available in the Pololu USB Software Development Kit
  • Optional CRC error detection to eliminate communication errors caused by Lärm or software errors
  • Optional Command-Time-Outs (switch off motors when communication stops)
  • supports automatic baud rate detection from 1,200 bps to 500 kbps, or can be configured with fixed baud rate
  • supports standard Compact and Polulu protocols as well as the Scott EdwardsMini SSC protocol and an ASCII protocol for easy serial control from a terminal program
  • Optional serial delay for communication with half-duplex controllers such as the Basic Stamp
  • Con
